TS-109 Pro Specification

TS-109 Pro
规格信息
购买→
Processor:

SoC 500MHz
Memory:

128MB DDR II RAM, 8MB Flash
HDD Capacity:

1 x 3.5" SATA I/II (the HDD is not included)
LAN Port:

1 x Gigabit RJ-45 Ethernet port
LED Indicators:

USB, Status, eSATA, HDD, LAN, Power
USB:

3 x USB 2.0, support USB printer,
disk, digital camera, pen drive, card reader, USB hub
eSATA:

1 x eSATA port
Buttons:

Intelligent USB auto copy button
Power Button
Reset Button
Alarm Buzzer:

System warning
Form Factor:

Portable desktop
Dimensions:

210(D) x 60(W) x 182(H) mm
Weight:

Net weight: 1.2Kg
Gross weight: 2.1Kg
Operation Environment:

Temperature 0~35°C
Humidity 0~95% R.H
Power Supply:

Input: 100-240V AC, 50/60Hz, Output: 12V DC, 3A
Power Consumption:

Sleep mode 6.6W
In operation 14.4W
Energy-saving Design:

Fanless, HDD sleep mode
Low power consumption & noise-free
Thermal Solution:

Heat dissipation by aluminum case
Secure Design:

K-Lock security slot for theft prevention
Power cord hook for kicking-off prevention
Sound Level: Standby: 26 dB
In operation: 33dB
注意：请仅使用 QNAP 内存模块来保持系统的性能与稳定性。若 NAS 设备有多个内存模块，请使用规格相同的 QNAP 模块，并参考硬件用户手册安装兼容的 QNAP 内存模块。
警告：使用不受支持的模块可能导致性能下降、引发错误或使操作系统无法启动。
QNAP 有权视供货商产品供货情况，更换部分零件或配件。其兼容性与稳定性皆经过相同严格的测试检验，请用户放心使用。
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
设计及规格若有变更，恕不另行通知。产品图仅供示意，实际产品可能有所不同。
由于屏幕显示误差，产品实际颜色亦可能和网站所示有所不同。

Powerful All-in-one Server

Software Specifications
Operation System:

Linux embedded system
Networking:

TCP/IP, DHCP Client, DHCP Server, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, DDNS, NTP, Jumbo Frame
File System:

EXT3 (Internal/external HDD)
FAT (External HDD)
NTFS (External HDD)
Supported Clients:

Microsoft® Windows® 98/ ME/ NT/ 2000/ XP/ 2003/ Vista/ Windows 7 (32bit & 64bit)
Mac OSX
Linux and Unix
Disk Management:

User quota management (Per user)
Disk usage status
Check disk (Check Linux file system)
Bad blocks scan
User Management:

Windows AD service support
User account management (max 256 users)
User group management (max 128 groups)
File System Management:

Network share management (max 256 Shares)
Share folder level ACL support
Unicode support
Journaling file system
Unique web file manager
System Tools:

E-mail alert (support SMTP authentication)
HDD standby mode setting
Disk usage alert
Auto power on after power loss
System firmware upgrade
Change homepage Logo
Backup, Restore, Reset system setting
Changeable Protocol Management
Easy IP Filter Control
Romote Login by SSH / Telnet connection
UPS Support
Network recycle bin
Event Log:

Display system log / alert / error
Multi-language:

English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, and Russian
Triple Backup Solution:

PC client backup software-NetBak Replicator: Instant/ Schedule/ Auto-sync backup
Remote Replication: Remote file backup
Unique Q-RAID 1 mirroring backup to external HDD via USB or eSATA
TS-109 Turbo Station
Adaptor
Power cord
CD-ROM (user manual, Quick Install Wizard and software inclusive)
Quick Installation Guide
Flat head screws x 4
Ethernet cable x 1
Stands x 2
Round head screws x 2
原包装出货的扩充卡、变压器及配件自购买日起享有一年保固。
