1. IEEE 802.3 Ethernet
2. IEEE 802.3u 100BASE-T
3. IEEE 802.3ab 1000BASE-T
4. IEEE 802.3bz 2.5G/5GBase-T
5. IEEE 802.1Q VLAN Tagging
6. IEEE 802.3x Full-Duplex Flow Control

1. Device connection status
2. Device health status
• System uptime
• CPU temperature
• Firmware version detect
3. Connected Devices
4. WAN status overview
• Link up / Link down

1. Customer defined WAN/LAN interface setting for each physical port
2. Physical interface setting status
3. WAN/LAN configuration
4. VLAN configuration
5. Bridge (port group) configuration
6. Network port connection status
7. IEEE 802.1Q virtual LAN (VLAN)
8. IPv4 / IPv6 routing management
• Routing table
• Static table
9. DDNS
10. DHCP table

1. Protocol-based firewall (TCP, UDP, ICMP, TCP+UDP)
2. Firewall rules based on domain names and IP addresses
3. Port forwarding and Network Address Translation (NAT)
4. Support FTP ALG, PPTP ALG and SIP ALG
5. DMZ

1. Secure remote access with L2TP, WireGuard, OpenVPN and QBelt (QNAP proprietary) protocol
2. Client IP pool configuration
3. VPN user management
• User status for QBelt / L2TP / OpenVPN / WireGuard
• User settings for QBelt / L2TP / OpenVPN / WireGuard
4. Connection logs
5. Secure remote access as VPN client with OpenVPN protocol

1. Parental control
2. Domain Name System (DNS) filtering and content filtering

1. Event logs
2. Restart, Reset, Backup, Audio Alert
3. Local account, QNAP ID, Remote management
4. Diagnostics network status
5. USB Settings: FTP Server, Device User, USB usage condition

1. Auto multi-site VPN
2. QuWAN QVPN management
3. Traffic monitoring using QuWAN Orchestrator
4. Quality of Service
5. Edge devices monitor

1. 50,000 concurrent sessions
2. 160 Mbps QBelt VPN performance(multiple tunnels)
3. 324 Mbps QuWAN performance
4. Max 700 QBelt connections support(Need managed through QuWAN)

* Actual performance may vary depending on network conditions and activated applications
