TS-100 Specification
| Processor: | SoC 200MHz |
| Memory: | 32MB DRAM, 4MB Flash |
| HDD Capacity: | 1 x 3.5" SATA I/II HDD, up to 1TB, expandable to 2TB via eSATA/USB (the HDD is not included) |
| LAN Port: | 1 x Gigabit RJ-45 Ethernet port |
| LED Indicators: | USB, Status, eSATA, HDD, LAN, Power |
| USB: | 3 x USB 2.0, support USB printer, |
| eSATA: | 1 x eSATA port |
| Buttons: | Intelligent USB auto copy button |
| Alarm Buzzer: | System warning |
| Form Factor: | Portable desktop |
| Dimensions: | 210(D) x 60(W) x 182(H) mm |
| Weight: | Net weight: 1.2Kg |
| Operation Environment: | Temperature 0~35°C |
| Power Supply: | External power adapter, 12V, 36W, 100~240V |
| Power Consumption: | Sleep mode 6.6W |
| Energy-saving Design: | Fanless, HDD sleep mode |
| Thermal Solution: | Heat dissipation by aluminum case |
| Secure Design: | K-Lock security slot for theft prevention |
 | |
警告：使用不受支持的模块可能导致性能下降、引发错误或使操作系统无法启动。
QNAP 有权视供货商产品供货情况，更换部分零件或配件。其兼容性与稳定性皆经过相同严格的测试检验，请用户放心使用。
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
设计及规格若有变更，恕不另行通知。产品图仅供示意，实际产品可能有所不同。
由于屏幕显示误差，产品实际颜色亦可能和网站所示有所不同。
